  • HP2P网络中群的分裂与合并方法
HP2P网络中群的分裂与合并方法 授权有效中;
  • 专利(申请)号: CN201110273600.1
  • 专利类型: 发明;
  • 主分类: H电学;
  • 产业领域: 电通信领域
  • 专利来源: 高校;
  • 申请日: 2011-09-15
  • 原始申请人: 西安电子科技大学
  • 当前专利权人: 西安电子科技大学
  • 交易方式: 转让;
  • 其他交易方式:
  • 参考价格(元): ¥50000
  • 联系方式: 远诺龚雪—18329540641

摘要

【 中文摘要 】本发明是一种HP2P网络中群的分裂与合并方法。本发明主要针对HP2P网络的上下层结点数量比例过大或过小会导致网络性能下降的问题, 提出一种HP2P网络中群的分裂与合并的方法, 通过计算结点间的亲和度将具有高亲和度的结点组织在一起, 以使网络保持恰当的层间比例, 从而维持HP2P网络的高效率、低负载和可扩展性。在群的分裂与合并方法中, 将亲和度因子放在消息中进行传递, 使得亲和度的计算简单, 容易实现。在群分裂与合并后网络的拓扑结构还可以得到一次优化。本发明可应用于HP2P网络, 还可应用于其它相似网络上的分裂与合并过程。

【 英文摘要 】The invention provides a method for splitting and combining clusters in an HP2P (hybrid hierarchical peer-to-peer) network. Aiming to solve the problem of the decreasing network performance caused by too large or too small ratio of the node numbers in the upper and lower layers in the HP2P network, the invention provides a method for splitting and combining the clusters in the HP2P network. Nodes with high affinity can be organized together by calculating the affinity among the nodes, so that the network can maintain a proper interlayer proportion, thus the HP2P network can be kept with high efficiency, low load and extensibility. In the method for splitting and combining clusters, an affinity factor can be transmitted in the message, so that the affinity can be simply calculated and is easy to realize. Besides, the topological structure of the network can be optimized after the splitting and the combination of clusters. The method provided by the invention can be applied to the HP2P network as well as the splitting and combination process of other similar networks.

技术摘要(来自于incoPat)

【 用途 】

信息通信网络对等(p2p)网络
方法过程其它方法过程拆分方法

【 技术功效 】

技术功效句主动群通过简单的通信获取被动群的超级结点集合; 因此群分裂后网路拓扑得到一次优化; 每个起始结点通过对裂群消息一次广播就可以实现群的分裂
技术功效短语简单通信; 拓扑得到优化; 获取被动群; 实现群分裂
技术功效1级复杂性; 拓扑; 获取; 分裂
技术功效2级复杂性降低; 拓扑改善; 获取; 分裂
技术功效3级通信复杂性降低; 拓扑改善; 被动群获取; 实现群分裂
技术功效TRIZ参数36-系统的复杂性;

分类号

【技术分类】

主分类号

H04L29/08;

  • H 电学

  • H04

    电通信技术

  • H04L

    数字信息的传输,例如电报通信(电报和电话通信的公用设备入H04M)〔4〕

  • H04L29/00

    H04L1/00至H04L27/00单个组中不包含的装置、设备、电路和系统〔5〕[2006.01]

  • *H04L29/02

    通信控制;通信处理(H04L29/12,H04L29/14优先)〔5〕[2006.01]

  • **H04L29/06

    以协议为特征的〔5〕[2006.01]

  • ***H04L29/08

    传输控制规程,例如数据链级控制规程〔5〕[2006.01]

IPC分类号
清洁能源产业分类2.1.2; 2.2.3; 3.3.3
数字经济核心产业分类010201; 010609; 030103; 030301; 030302; 030303; 030304; 030305; 030306; 030307; 030403; 030404; 040101; 040102; 040103; 040104; 040501; 040502; 040503; 040703

【行业分类】

国民经济行业分类

制造业信息传输、软件和信息技术服务业居民服务、修理和其他服务业

国民经济行业(主)

制造业信息传输、软件和信息技术服务业居民服务、修理和其他服务业

新兴产业分类

下一代信息网络产业数字创意技术设备制造

新兴产业(主)

数字创意技术设备制造

知识密集型分类

信息通信技术制造业信息通信技术服务业新装备制造业

学科分类

工程

专利历程

  • 2011-09-15

    申请日

    CN201110273600.1(当前专利)

    申请号

  • 2012-01-04

    首次公开日

    CN102307238A

    首次公开号

  • 2014-09-17

    授权公告日

    CN102307238B(当前专利)

    授权公告号

  • 2031-09-15

    预估到期日

    计算因素


其他著录项

代理机构陕西电子工业专利中心 61205
代理人程晓霞; 王品华
申请语言汉语
审查员李文娟

×
